You're looking at PVC sheathed power cable with either copper or aluminum core, and we've got steel tape armor on VV22/VLV22 series for when you're burying it underground or running it through tunnels where mechanical stress is a real concern. It's low to medium voltge, 1.5mm² up to 630mm², and we do 1 to 5 cores including 3+1, 4+1, or 3+2 configurations — basically whatever your project needs. Most buyers go with the copper core for better conductivity, but alumnum keeps the cost down if that's your priority.
We carry ISO9001, ISO14001, and 3C certs, so compliance isn't something you'll have to chase down. Flame retardant and halogen free options are avaliable, though the standard temp rating is 70°C and the minimum bending radius is 15 times the cable diameter — check your insallation specs against that. We usually have stock on common sizes, but confirm lead time for anything over 50mm² or so.
It's not suited for direct exposure to high heat or constant flexing; this is a fixed installation cable for construction, power stations, or industiral sites where you need reliability more than flexibility. We follow GB and IEC standard, so you're getting something that's been tested in real-world conditions, not just a spec sheet promise.
Anyway, one thing you might not think to ask is that the steel tape armor adds noticeable weight, so factor that into your handling and support structure planning — it's a solid choice for underground runs but a pain in tight conduit.
For copper core cables in that range, MOQ is typically 500 meters for standard sizes. For aluminum core, it's a bit more flexible—usually 300 meters is fine. If you need less, just ask, we might be able to work it out.
No, we don't mix core materials in one cable. Each cable uses either all copper or all aluminum cores. For 4-core designs, you'd pick one material for all cores.
Yes, absolutely. We include ISO9001, ISO14001, and 3C certificates with every batch. You'll get them along with the test reports and packing list.
For a large cross-section like 630mm², lead time is around 25-30 working days after order confirmation. Standard sizes under 240mm² usually ship in 15-20 days.
Yes, we use wooden or steel drums, wrapped with waterproof film and strapped. For smaller orders under 500m, we can coil and pack in woven bags. Just specify your preference.
