7 minutes of flight time is what you're working with here, and that's teh first thing to know — it's tight for a spray drone, but the 295mm wheelbase keeps it nimble in smaller fields or orchards where bigger rigs just can't maneuver.
What it does is carry up to 1.5kg of liquid with a dual pump system that hits 4L/min at the top end, and the flow meter keeps error within about 2% so you're not wildly overspraying or missing strips. The 50A ESC and 2807 1350KV motors handle a level 7 wind pretty well, but don't expect it to hold a perfect line in a real gust — the ±1cm horizontal and ±2cm vertical accuracy (RTK) is solid for most precision work, though.
Front and back obstacle sensors are included, which is nice for tight spaces, and the 1.6W 5.8G image transmission with the FPV H1 camera lets you see what's happening in real time. Night ops are possible with dual LED lights, but we usually see buyers stick to daylight hours for spraying anyway.
You'll need a 3300mAh to 4400mAh 6S battery with an XT60 plug — we don't include one, so factor that into your setup. The 7040 propellers are a standdard size, and the whole thing ships in a reinforced box, usually with the camera and transmitter separate to avoid damage in transit.
4L/min is the max flow rate, but most users dial it back to 2-3L/min for better coverage on row crops or vineyards — the 2% flow meter accuracy holds across the range, which is tighter than some cheaper units we've seen. Operating temp is -10°C to 40°C, so it's fine for spring and summer work in most climates, but don't push it in a heatwave.
Lead time is typically 15-20 working days or so, and we usually have stock on the base model but confirm if you need the CE or ISO certs included in the paperwork. The MOQ is 1 unit, but shiping costs drop noticeably at 5 or more.
It can handle up to 1.5kg of liquid payload. Keep in mind that with a full tank, your flight time will be around 7 minutes using a 3300-4400mAh 6S battery.
No minimum order quantity — we can ship a single unit for testing or small-scale use. Bulk orders get better pricing, though.
Yes, we have CE, ISO 9001, and ISO 14001 certifications available on request. They are included with the product documentation.
It means the drone can hold its position within 1cm horizontally and 2cm vertically using RTK or GPS, so you get precise spray coverage with minimal overlap or gaps.
We pack it in a sturdy foam-lined box with all components secured — the frame, ESC, motors, and FPV camera. No special storage conditions needed, just keep it dry and between -10°C and 40°C.
