3W UV Laser Marking Machine for High Precision Engraving on Plastics Metals Glass

Actually, we've been shippng these UV-BT-3W units for a couple of years now, and the 3W power is pretty much the sweet spot for most small to mid-volume marking jobs—it handles plastics, metals, and glass without leaving burn marks or discoloration like CO2 or fiber lasers sometimes do.

The 355nm wavelength is what makes it different, since that's a UV beam that basically cold-marks the surface rather than heating it up, so you can engrave things like smartphone back panels or medical tools where even a tiny heat-affected zone would ruin the part, and it's better than reagent grade for this kind of precision work because teh minimum line width is under 0.1mm and the repeat accuracy sits at ±0.002mm (most buyers don't realize that's tighter than what a lot of fiber lasers can manage).

One thing we've seen is that people who try to etch deeply into stainless steel with the 3W model are usually disappointed—it's not suited for deep engraving, as the max depth is only about 0.2mm or so, but for surface marking like serial numbers or logos it's actually ideal.

The control system runs on Linux, which sounds odd at first, but what it does is keep the interface stable without crashes, and you can feed it files form CorelDraw or AutoCAD directly, though the software compatibilty list also includes BMP and PLT if you're working with older vector formats.

Air cooling is a nice touch because you don't need a chiller or water lines—it's basically plug-and-play if you've got a standerd 220V outlet, and the whole unit is only about 45kg so one person can usually move it around the workshop, but confirm lead time on the 5W and 10W options since we usually have stock of the 3W version.

And the marking speed goes up to 9000mm/s, but in practice most jobs run at around 3000-5000mm/s depending on the material and contrast you're after, and frequency range of 10-200kHz lets you dial in the pulse for different plastics or coated metals.
