High Capacity 6V 200Ah AGM Battery Supplier for Golf Carts and Wheelchairs

It's not a compact unit by any stretch at 26.5kg, so if you're working with limited space or need something you can easily lift, this 6V 200Ah AGM battery probably isn't ideal—the FCD6-200 is a heavy beast, and that's just the reality of what's inside.

But for a golf cart or wheelchair where you're swapping batteries maybe once every few years and can handle the weight, it actually works pretty well; we've seen most buyers go with this for deep cycle appliction because the 200Ah capacty at the 20hr rate gives you roughly 8 hours of runtime in a standard cart, and the 1200 cycles at 50% DOD means you'll get good three to five years before it starts dropping off.

The sealed AGM construction means no acid to spill and it's pretty happy from -40°C to +65°C, so it'll handle a cold garage or a hot trailer without complaining, and the self-discharge rate is under 3% per month—basically, you can park it for a few months and it'll still crank right up.

Specs-wise, you're looking at a nominal 6V DC with a max discharge current of 600A for about 5 seconds, which covers those heavy start-up loads on a motor, and the recharge votage sits between 7.2V and 7.5V; it's also certified to JISC8702 and IEC60876-2 standards, so compliance-wise it's tighter tolerance than most generic imports (usually 2-4 weeks for a COA if you need one).

We typically ship these in single units or pallets of 20 or so, with F1 Faston terminals standard—check lead time if you need custom connectors, as that's not something we stock routine.

Anyway, the 8-year design life is optimistic for heavy use, but the 3-year warranty is solid for what it costs, and the 226mm height includes terminals so measure twice if you're fitting it into a tight compartment.
