We see these units mostly in smaller clinics and mobile dental setups where space is tight and you can't afford downtime during a procedure—like those 4-hour backup power windows actually get used when the mains flicker in older buildings.
Tidal volume runs form 50 to 1500ml adjustable, respiratory rate 4-40 bpm, I:E ratio 1:1.5 to 1:3.0, and the flowmeters handle O2 and N2O from 0.1 to 10 L/min each. It's not for high-acuity OR cases though—the manual mode is there, but the IPPV and SIPPV are really what you'll lean on for routine work.
That automated self-check at startup saves you a headache when you're setting up between patients; the infrared turbine sensor basically confirms teh ventilator's actually moving air before you connect the circuit. Vaporizer concentration goes 0-5% across double slots, so you can run sevoflurane and isoflurane side by side (or so design intends—most buyers just use one slot).
Pricing starts at $2,850 per unit for samples, drops to $2,450 each for 10-49 units, and $2,150 per unit for 50+. You get CE and ISO13485 certs with every machine—no LCD display on this model, but we usually have stock ready in about 20 days or so, though confirm lead time if you're ordering over 50 units.
Packing comes in two cartons—83x77x123cm for the main unit at 79kg, plus a 66x62x35cm box at 16kg—so factor that into freight costs. The high precision flowmeter is actually better than some hospital-grade units we've seen for holding O2 delivrey within 0.1 L/min increments, which matters when your titration margins are thin.
MOQ is typically 1 unit for stock models, but we can discuss larger volumes if you need a custom batch.
Yes, the unit is CE and ISO13485 certified, and we include the certificates with every shipment.
Yes, the built-in backup power supply supports at least 4 hours of continuous operation, so you're covered during transport or power interruptions.
It ships in two cartons: the main unit in an 83x77x123cm box and accessories in a 66x62x35cm box. Total weight is about 95kg.
Standard lead time is 15–20 business days after order confirmation, depending on stock. We can expedite if needed.
