We've run this on MDF and solid oak, and the 60m/min rapids on X and Y actually hold up under load — not just on paper. It'll clear a full 2440mm sheet in roughly 2.5 minutes or so on a simple profile path, which is better than most comparably priced units we've seen.
The worktable is 1270x2440mm, so it takes a standdard 4x8 sheet without overhang, and the vacuum hold-down is decent for flat panels but don't expect it to grip warped stock reliably. Z-axis travel is 200mm, which is enough for most panel carving but tight for thick timber — you'll want to check your bit projection if you're doing 150mm deep work.
That 22kW power draw means you need a solid 380V line, preferably 50Hz, and it'll pull about 40 amps at full load. Teh machine itself weighs 3300kg, so plan your floor loading — it's not a benchtop toy, but the mass helps damp vibration during heavy cuts. ISO and CE certs are standard here, nothing fancy.
Most buyers go with ATC version for — tool changes at 60m/min are pretty much, but if you're only doing one-off parts, the manual tool change variant is cheaper and easier to maintain. We usually have stock on the 1325 model, but confirm lead time if you need the extended warranty past 24 months.
Basically, it's a solid mid-range machine for cabinet shops or sign makers who want speed without stepping up to a 35kW spindle. It's not suited for fine jewelry work or micro-machining — the spindle runout is around 0.01mm, which is fine for wood but not for brass or aluminun unless you take light passes.
Anyway, ordering is straightforward: you'll need to specify 380V/50Hz or our company can adjust for 60Hz regions, but that adds a couple weeks to delivery. The standard package includes the control system, vacuum pump, and basic tooling — just add your CAM software and you're within a day of setup.
We usually start at 1 unit for this model, so no need to worry about a big MOQ. If you're ordering multiple, we can talk about a volume discount.
Typical lead time is around 15-20 working days, depending on current production load. We'll confirm exact timing once we process your order.
Yes, we include both ISO and CE certifications with every AS-S-1325-ATC1. You'll get the digital copies right after payment, and hard copies shipped with the machine.
We can adjust the worktable size or Z-axis travel for custom orders, but that will affect both lead time and price. Let us know your exact specs, and we'll quote you.
Keep it in a dry, indoor space with stable temperature, ideally between 5°C and 40°C. Avoid high humidity to prevent rust on the rails and electrical issues.
