We've got 150 units in stock right now, lead time is about 2-3 weeks for larger orders, and the MOQ is 10 pieces — each one stands 600mm tall and weighs 0.74kg, so it's not too heavy for a single person to handle on a roof mount.
Basically, this antenna is built for drone defense systems where you need that 360° coverage, and the 8±1dBi gain gives you a solid signal footprint without overcomplicating things — the vertical beamwidth is tight at 15±5°, which actually helps focus energy where you need it.
But it's not really suited for indoor use or low-power setups, the 50W rating means you're feeding it form a proper amplifier, and the N-K connector is standerd for that kind of gear — just make sure your cable run isn't too long or you'll lose signal in the feedline.
fiberglass shell is IP67 rated, so rain and dust are fine, and it'll handle wind up to 60m/s without snapping — we usually have these mounted on poles in coastal areas, and they hold up well even in storms, though I'd check the bracket hardware separately.
One thing buyers don't always ask about is the tempearture range — it's -40°C to +70°C, which covers most outdoor installs, but if you're in extreme cold the VSWR might drift slightly (it's ≤1.5 at room temp, but we've seen it hit 1.6 in deep freeze).
Anyway, if you're ordering for a perimeter defense system, the 720-860MHz band is what we ship by default, but our company can customize the center frequency if you tell us your exact band — just note that customiztion adds roughly 10 working days or so to teh delivery.
We can do small batches—MOQ is typically 10 units for stock orders, but if you need fewer for testing, just ask and we can work something out.
Standard lead time is 15-20 working days after order confirmation. If you need a rush, we can sometimes expedite to 10 working days depending on current production load.
Yes, we include a factory test report for VSWR and IP67 rating with each shipment. Third-party certification is available at an extra cost if your project requires it.
Absolutely—we can tune it to any specific frequency in that range. The 8±1dBi gain stays consistent across the band, so no performance drop.
Keep it in a dry, indoor space at room temperature, away from direct sunlight and heavy moisture. The fiberglass body is durable, but long-term exposure to extreme temps isn't recommended.
Logistics were handled exceptionally well, with the package arriving ahead of schedule and in perfect condition. The shipping updates were precise and timely, which made tracking effortless. Regarding the item itself, the build quality is immediately impressive; the fiberglass housing feels incredibly robust and well-constructed, designed to withstand outdoor elements. The finish and assembly show clear attention to detail. Customer service was also highly responsive and professional, answering my pre-purchase questions promptly and accurately. The overall experience from ordering to delivery was seamless and efficient. This level of service and product presentation is commendable and sets a high standard. I am very satisfied with this transaction and would confidently recommend this supplier based on this experience alone. The antenna appears to be a solid, high-grade component, exactly as described, and I have no concerns about its durability or performance for its intended application. The entire process reflected a company that values customer satisfaction and operational excellence.
