Factory Supply Foldable Joyance 40L Agricultural Drone Sprayer, Customized Farming UAV for Pesticide Spraying with 12m Width & 16Ha/hr Efficiency

Introducing the Joyance 40L Foldable Agricultural Drone Sprayer, a cutting - edge solution for modern farming needs. This UAV is designed to revolutionize agricultural spraying and fertilizing operations, offering high efficiency, durability, and customization options to meet diverse farming requirements.

### Key Capabilities and Design

The drone comes with a 40 - liter pesticide tank and a 70 - liter fertilizer tank, enabling large - scale farming operations without frequent refills. Its spraying system, equipped with 4pcs centrifugal nozzles, achieves a spraying width of 10 - 12m (when 1 - 3m above crops) and a remarkable spraying efficiency of 16 hectares per hour, ensuring quick coverage of vast farmlands. The foldable design, combined with an aviation aluminum alloy and carbon fiber frame, makes it both durable and lightweight, easy to transport and store.

### Power and Performance

Powered by an 18s 30000mAh intelligent battery (with ≥600 cycles), the drone supports 10 - minute fast charging (from 30% - 99% at 220V) via an 8000W quick charger. The heavy - duty brushless motors (Hobbywing) feature IP68 waterproof and dustproof rating, along with a self - cooling system, allowing continuous work for up to 12 hours per day. The drone can resist winds of up to 10m/s, ensuring stable operation in various weather conditions.

### Structural and Operational Advantages

The split frame design, made of high - strength aluminum alloy and 50mm high - rigidity carbon fiber arms, ensures stability and durability. A 4G RTK antenna reduces magnetic interference, enhancing flight stability and safety. Built - in weighing sensors real - time correct data deviation during flight, and the drone has no - material detection and blanking abnormality detection functions. It can judge the absence of material/solution by weighing and stop flying immediately after operation to avoid empty flights, and trigger an alarm when spreading/feeding speed is abnormal.

### Product Parameters

- **Product Name**: JT40L - 404 Agricultural spreader Drone
- **Fly Time**: No - Load Hovering Time 20Min, Full Load Working Time 10Min
- **Water Tank Capacity**: 40 Liters
- **Spraying Width**: 10 - 12m (above crops 1 - 3 m)
- **Weight**: Self Weight (without battery) 48.4KG (with 1 battery), Full Load Weight 80 ~ 100KG
- **Spraying Efficiency**: 16Ha/hr (work continuously)
- **Spraying Speed**: 10 m/s
- **Size**: Expand Size 1850*1520*930mm, Fold Size 1050*900*930mm
- **Smart Battery**: 18s 30000mAh (≥600 cycles)
- **Product Material**: carbon fiber + aviation aluminum alloy
- **Packing Size**: 160*130*120CM
- **Spraying System**: 4pcs centrifugal nozzle
- **Charger**: Quick charger 8000W
- **Wind Resistance**: 10m/s
- **Charging Time**: 1pc 10 min (30% - 99%, 220V)
- **Spraying Flow**: 13L/Min (adjustable)
- **Temperature**: Battery temperature is below 60°
- **Motor System**: Hobbywing
- **Waterproof Level**: Motor IP68, Whole Drone IP57
- **Flight Control System**: JOYANCE

### Customization and Supply

As a factory - direct supplier, we offer wholesale and customized services for the Joyance 40L Agricultural Drone Sprayer. Whether you need adjustments to tank capacities, frame design, or additional features, we can tailor the drone to your specific farming needs. This drone is ideal for large - scale farms, agricultural cooperatives, and professional farming service providers, helping to improve spraying and fertilizing efficiency while reducing labor costs.
