layup schedule uses a 6-8 mm fiberglass laminate with a gel coat surface, which gives it better UV resisance than a painted polyester part — we’ve seen these hold color for over a decade in direct sun. The resin system is isophthalic, not orthophthalic, so it won’t bloom or chalk as fast in chlorinated water, and the hand-layup process lets us dial in wall thickness at stress points like the entry lip and exit flume.
You’re looking at a load range of 100-500 kg with a maximum of 5 passengers, but the real limit is loading during wet use — the fiberglass handles about 1.5x the static rating before any microcracking shows up in the gel coat. We run a 24-hour water soak test at 40°C on every third unit, checking for blistering or delamination, and the CE mark covers the structural integrity for commerical parks.
Customiaztion means our company can adjust the slide radius, drop height, and exit angle, but the mold tooling for a one-off shape adds 3-4 weeks to lead time — standard curves are faster. Color matching to a RAL or Pantone is no problem, but metallics or pearlescent flakes require a 15% surcharge on the gel coat because the mica loading changes the spray viscosity.
The end style with a pool termination uses a submerged flange that bolts into a concrete basin, and we include stainlss steel inserts for the anchor points — no galvanic corrosion against the fiberglass. Without a pool, the slide terminates in a flat landing zone with a rubberized edge strip, but you’ll need to account for a 2-meter runout distance for adult riders.
Packing is bubble film and cotton cloth, which is fine for container shiping, but if you’re doing LTL freight, we recommend upgrading to a plywood crate — about 150 USD extra, and it prevents edge chipping during transfers. We usually have stock on DP-WSS0312P in the standard 6-meter length, but confirm lead time for custom sizes.
The pump is sold separately because most parks already have a filtration and recirculation system, and the slide’s water inlet is a 2-inch NPT fitting — pretty standard. Actually, one thing buyers don’t always ask about is the gel coat thickness; we target 0.5-0.7 mm, and anything below 0.4 mm will show fiber pattern after two seasons in high-traffic use.
We can work with a single unit for custom orders, but standard MOQ is typically 1-2 pieces depending on the design complexity. Just let us know what you need.
Lead time is around 15-25 working days after order confirmation, plus shipping time. Custom colors or sizing might add a few extra days.
Yes, it's CE and ISO9001 certified. We include those certificates with the shipment, and we can also share test reports for the fiberglass material upon request.
We keep the 6-8 mm thickness as standard for most custom sizes to balance durability and weight. For very large or high-load slides, we might recommend thicker layers, so let us know your specs.
It's wrapped in bubble film and cotton cloth, then packed in a wooden crate. That setup protects it well for ocean or air freight, and we've shipped hundreds without issues.
